PH Transmitter with Galvanically Isolated Output

Get a Price/Quote

MOQ : 1 , , Unit

PH Transmitter with Galvanically Isolated Output Specification

Color
Grey

Application
Industrial

Voltage
220 Volt (v)

Material
Metal

Product Type
PH Transmitter with Galvanically Isolated Output

Size
Standard

PH Transmitter with Galvanically Isolated Output Trade Information

Minimum Order Quantity
1 , , Unit

Supply Ability
2 Units Per Week

Delivery Time
1 Week

About PH Transmitter with Galvanically Isolated Output

The HI 8614LN is a water-resistant pH transmitter is designed to be used with a standard high impedance pH probe with BNC connector. The signal is then processed by a special high-impedance amplifier, which transmits an output current directly proportional to the input signal but independent of changes in load or cable capacitance.

Product Details:

Water resistant
Loop powered
Automatic Temperature Compensation
LCD Screen

Technical Specification

Range	0.00 to 14.00 pH; 420 mA
Resolution	0.01 pH; 0.01 mA
Accuracy @ 20C	0.02 pH; 0.02 mA
Calibration	offset: 2 pH; 2.2 mA; slope: 86 to 116%; 0.5 mA
Temperature	fixed or automatic from 0 to 100C (32 to 212F) with HI 76608 probe
Input Impedance	1012 Ohm
Recorder Output	4-20 mA (isolated)
Protection	IP65
Power Supply	20-36 VDC
Load	max 500 Ohm
Environment	0 to 50C (32 to 122F); RH max 95% non-condensing
Dimensions	165 x 110 x 71 mm (6.5 x 4.3 x 2.8)
Weight	1 kg (2.2 lb.)
